USB 3.0 Type-C to 4x USB Type-A Hub
USB 3.0 Type-C to 4x USB Type-A Hub
Enlarge

USB 3.0 Type-C to 4x USB Type-A Hub

CSV-1541 The SenseVision USB 3.0 Type-C to USB Type-A Data and Charging Hub is a compact tool which adds four common USB Type-A ports to your USB Type-C enabled device. Many of the latest Ultrabooks and Laptops lack a sufficient number of expansion ports, thus making it difficult to use your favorite peripherals like Mice, USB Storage and External HDD’s at the same time, while no port is left to charge your Smartphone, headset or other device. This USB Hub gives you four additional USB Type-A ports for Data and Power. It features fully integrated voltage regulators and Port 5 supports the comprehensive USB Battery Charging Specification 1.2 which supports the following three (Rapid) Charging modes: SDP, CDP and DCP. With this Hub, battery charging can now be done safely for a wide range of portable devices.
The current limit of USB charging is 500mA for USB 2.0 and 900 mA for USB 3.0. Depending on the device, Rapid Charging features limits between 1000mA and 2000mA. Rapid Charging allows charging at higher current than the USB Spec but requires both Host and connected devices to support this functionality. There are three supported USB Charging Modes:

• SDP: Standard Downstream Port (USB 2.0 500mA, USB 3.0 900mA charging + Data)
• CDP: Charging Downstream Port (up to 1500mA for supported devices + Data)
• DCP: Dedicated Charging Port (beyond 1500mA for supported devices, NO Data)

All major operating systems including Windows, Apple OS X, Chrome OS and Linux are supported without the need of installing a driver. Functionality depends on the USB Host controller in your device.

Related products
USB 3.0 Active Repeater Cable 15 m/ 49 ft Male/Female
USB 3.0 Active Repeater Cable 15 m/ 49 ft Male/Female
USB 3.0 3-Port Hub with Gigabit Ethernet
USB 3.0 3-Port Hub with Gigabit Ethernet
USB 3.0 Active Repeater Cable 10 m/ 32 ft Male/Female
USB 3.0 Active Repeater Cable 10 m/ 32 ft Male/Female

Specifications

Model
Product Name: USB 3.0 Type C to 4x USB Type A Hub
Product Series: SenseVision
Weight: 51 gr
Cable length: 185 mm
Item Code: CSV-1541
EAN Code: 8719214470531
UPC Code: 841615100712
Interface
USB 3.0 Type C x1
Voltage
1.2V Core Power
3.3V Suspend Power
5V Regulator for 5- 3.3V Output
Output Configuration
USB 3.0 Type A x3
USB 3.0 Type A with BC 1.2 Charging support x1
In the package
SenseVision USB 3.0 Type C to 4x USB Type A Hub
Quick install guide
Features:
• Reversible USB Type C connector (male)
• Compliant to USB 3.0 Specification, backwards compatible with USB 2.0 Specification
• USB 3.0 Data and Fast Charging through a single cable
• Supports USB 3.0 SuperSpeed data up to 5Gbps
• Supports USB Battery Charging Specification 1.2 (Port 5)
• Support for Vendor specific Charging Modes
• Works out of the box with Windows, Apple OS X, Chrome OS, no driver needed
• Works with all USB Type C enabled devices
The minimum requirements for the PC are:
CPU: AMD or Intel Dual Core CPU 2GHz or higher processor clock.
GPU: AMD, Intel or Nvidia
RAM: 1GB or higher
USB 2.0, 3.0 or 3.1 Type C Output
Supported Operating Systems:
Windows 7 (32 & 64 Bit)
Windows 8.1 (32 & 64 Bit)
Windows 10 (32 & 64 Bit)
Apple OS X
Chrome OS

Technology

USB

Developed in the 1990s, USB has become the most successful computing interface yet. The throughput has improved from 1.5Mbps to 10Gbps through standards evolution
1998 USB 1.x Low Speed LS 1.5Mbps Full Speed FS 12Mbps
2000 USB 2.0 High Speed HS 480 Mbps FS/LS
2001 USB on the Go USB 2.0 OTG Master / Slave configurable
2008 USB 3.0 USB 3.1 Gen 1 Super Speed SS 5Gbps / HS/ FS / LS
2013 USB 3.1 Gen 2 Super Speed +  SS+ 10Gbps SS/HS/FS/LS
2014 USB Type C USB 10Gbps DP 8.1Gbps and Power 100 W
