CLUB 3D Multi Stream Transport

Display devices have always been an integral part of the PC experience. Whether it is in the form of a desktop monitor, a notebook’s embedded panel, or the touch screen of a PC tablet, display devices play a vital role in defining the user’s visual experience.

The Club 3D MST hub is a hub device that receives a DisplayPort™ 1.2 MST signal from the source device and splits up and routes the video streams independently to each display device. Using this type of configuration also allows the use of non DisplayPort™ 1.2 monitors. Non DisplayPort™ outputs, such as VGA, DVI or HDMI®, the Club 3D MST hub is DP++ and can actively convert the DisplayPort™ signal to the other types of display interface signals.


Advantages

Increased productivity

The biggest advantage for designers, gamers or anyone is an increase of productivity having multiple screens.

A study done by the Jon Peddie Research, productivity increases an average of 42% when using multiple displays.

Multiple programs simultaneously

Most users have some type of workflow that involves multiple programs at any given time. Having multiple screens makes a much less painful experience and more productive.

Sharing data

Sharing data between applications is very common, for example dragging an image from a file folder to the Photoshop app. All these things can be streamlined with the help of multiple screens.


Surface pro port


Add on

Get even more from your Surface Pro 2 tablet with its powerful DisplayPort output.

Microsoft Surface Pro 2 has a powerful 4th Generation Intel Core i5 and with the Club 3D MST Hub is capable to drive up to 3 external displays*

*by using 3 external displays will disable the tablet screen

True AudioAMD TRUE AUDIO & DDM AUDIO

The Club 3D MST Hub supports DisplayPort 1.2 multi video and audio stremas. Paired with AMD Radeon R9 290 series and R7 260 series graphics cards, it features the first discrete GPU in the world with a programmable audio pipeline. TrueAudio Technology is designed for game audio artists and engineers to bring their artistic vision beyond sound production into the realm of sound processing.

Sound is a critically important part of the immersive experience for gamers and sound engineers are eager to advance their art, but they haven’t enjoyed the same kind of attention that continually drives graphics improvements.

womanphotshop

Ultimate in Color and Image Quality

Ideal for photography, graphic design, media creation and other color-critical applications. DisplayPort output can only support 10 bit video*

MST hub input pixel data depth 6/8/12 bits and supports output pixel format RGB444
*For 10 bit video you need a display that supports 10 bit video.
A DisplayPort connection between the display and video card and a video card that supports 10 bit video.If necessary, you need to enable 10 bit video support in the video graphics driver.
Software that supports 10 bit drawing using OpenGL or DirectX on Windows



eyefinity

AMD EYEFINITY

Enjoy the ultimate immersive gaming experience

With AMD Radeon based graphic cards, you can support up to 6 displays by using two MST hubs* working each monitor independantly or create a Single Large Surface (SLS) mode

*Requires a compatible graphics card supporting at least two DisplayPort outputs and 6 displays

Dual Mode

Also known as DisplayPort++ can directly output single-link HDMI, VGA and DVI signals using a simple passive adapter that adjusts from the different connector and the lower voltages used by DisplayPort. Club 3D MST Hub makes it easy and cost effective so you can use any monitor you want.

Ultrabook

Give your Ultrabook more displays

Ultrabooks and notebooks are increasingly becoming more powerful and smaller in the physical form factor. DisplayPort provides that flexibility to power several displays through a single port. With the MST Hub you can work with multiple displays and with its small form factor you can bring it along at work or home.



MST Hub FrontKey Features

Standards compliance/support:displayport v1.2, displayport v1.1a,VESA DDM

Standard,HDCP V2.0,DisplayId,and EDID V1.4

Supports main link rates of 5.4 bps(HBR2),2.7 bps(HBR)and 1.62 bps(RBR) from source

Supports 1/2/4 lanes of main link for RX side

Supports three DP++ output port,or two dual-link DVI ports,or the combination of ports

For DP 1.2 source,supports DP1.2 MST multi video/audio steams

Supports 1.1 source,supports ViewXpand

Supports DP-DP Bypass mode

Supports AUX-CH enables SBM and I2C mapping over AUX between the source/sink and device

Dedicated I2C slave for main processor to access the device

Supported output resolution:up to 2560X1600@60Hz each monitor in DP1.2 MST and up to FHD/1080p in DP1.1 or DP 1.2 SST

Input pixel data depth 6/8/10/12 bits and supports output pixel format RGB444

Awards

Silver Oca recommended

Size

Size



PDF Download:

CSV-5300 Product Information Sheet [EN]
CSV-5300 User Manual

High Resolution Image:

CSV-5300 High Resolution Image

Specifications

Model

Product Name: Club 3D Multi Stream Transport (MST) Hub DisplayPort 1-3
Product Series: SenseVision
Item Code: CSV-5300
EAN Code: 8717249411918

Interface

DisplayPort 1.2 Hub 1-3

Voltage

Input: 5V+/- 10%
Output: 3.3V +/- 10%

Output Configuration

DisplayPort 1.2 x 3

In the package

Club 3D Multi Stream Transport (MST) Hub

System Requirements

DisplayPort 1.2 supports up to twice the bandwidth of DisplayPort 1.1a (HBR). High Bit-rate 2 (HBR2) provides up to 5.4Gbps/lane of bandwidth, or up to 21.6Gbps in a full four-lane configuration. This lends itself very well to many applications that require ultra-high bandwidth.

DP 1.2

The number of display devices and also timings at which each display device can be driven will depend on the available bandwidth.

HBR

Graphics cards (only with the ones that has DisplayPort or Mini DisplayPort output)
