Overview

Radeon Graphics
AMD Catalyst configuration software
CrossFire Ready
Eyefinity 2.0
AMD HD3D
DirectX 11.1
7.1 HD Surround Sound
4096 Ultra HD
OpenGL 4.2
OpenCL 1.2
DisplayPort 1.2
FAST HDMI 1.4a
Dual Link DVI-I
Dual Link DVI-D
CoolStream High Performance Cooling
Overclocked Performance
royalKing PokerSeries
PCI Express 3.0



tl_files/club3d/uploads/en/content/Graphics cards/Poker Series/logo_pokerseries.png

royalKing

Club 3D proudly presents the Club 3D Radeon™ HD 7790 royalKing graphic card, play your games in high detail and experience full 1080p HD. With PokerSeries Club 3D offers a new level of special gamecards that delivers the best performance, newest features and best CoolStream coolers. The royalKing presents our highest demands.

Get ready for the future with 28nm GPU technology, Graphics Core Next Architecture, AMD App Acceleration and support for Ultra HD 4096p resolutions and PCI Express 3.0.



royalKing

CoolStream High Performance Cooling Technology

If you expect above average performance of your Graphics card, Club 3D CoolStream High Performance Cooling Technology is just the kind of high performance that you have been looking for.

Club 3D CoolStream features high performance heatpipes that keeps the components cool and outperforms standard cooling solutions. Paired with a unique fan blade design it increases airflow while reducing noise. The result is a dramatic increase of performance for your gaming and multimedia experience.

OverclockedExtreme Gamers require Extreme performance. The PowerSeries royalKing GPU's has been cherry-picked for extreme performance. Club 3D has developed a custom PCB to accommodate faster speeds and thermal dissipation. At 45MHz faster than the reference clock of 1030MHz, you will be running faster, efficient and more reliable out of the box without you having to do anything at all. You can be assured that the royalKing series won't let you down.



The Best Games
Club 3D offers the newest most demanding AAA game titles with this card, there is no question. Find out more  here.


SHOWCASE RADEON HD 7790 SERIES REALTIME DX11 GRAPHICS

With 896 stream processors, a 128 bit GDDR5 memory bus that provides 1.79TFLOPs of computing performance, the Club 3D Radeon™ HD 7790 royalKing graphics cards are intended for gamers who never settle. Equipped with AMD Graphics Core Next Architecture and the latest power management technology, the Club 3D Radeon™ HD 7790 royalKing is primed to enable astonishing performance and breathtaking image quality, making it the only solution for gamers who demand the best.

NEW FEATURES


EYEFINITY
 2.0

Eyefinity 2.0

Eyefinity™ 2.0 technology features all-new support for Stereo 3D, universal bezel compensation and brand new display configurations which allows the user to configure custom resolutions and the ability to relocate the Windows task bar to an arbitrary screen.




DDMADIGITAL MULTI-POINT AUDIO (DDMA)

The next step in audio output from a graphics card. Traditionally video cards has been able to output audio through the HDMI port and audio has been restricted to to a single device, be it a monitor, HDTV or a receiver.

With DDMA now you can send audio to multiple devices via the DisplayPort combined with the HDMI.

Imagine a video conferencing where each attendee is mapped to a monitor and with DDMA set on each monitor speaker set.


Graphics Core Next (GCN) Architecture and AMD App Acceleration

GCN

A revolutionary new architecture. Jump right into GPGPU applications today with Microsoft C++ AMP™ and OpenCL™ for spectacular performance with the GCN architecture. From video editors to Internet browsers, AMD App Acceleration™ is a supercharger for everyday applications. The Club 3D Radeon™ HD 7790 royalKing was engineered for the revolution in GPU compute.






ZEROCORE POWER

AMD is introducing with the Southern Islands chipset their long idle power saving technology. Now the graphics card can turn off most of its functional units of the GPU, when they are unused, leaving only the PCI Express bus and other components active. This as a result, reduce the power consumption in long idle, a power level low enough that ZeroCore Power shuts off the fan as there is no heat generated further saving energy.

ZeroCore Power will put CrossFire™ grapics cards in ZCP when not in use.


HD3DAMD HD3D

AMD HD3D™ is a technology designed to enable stereoscopic 3D support in games, movies and/or photos. Additional hardware (e.g., 3D-enabled panels, 3D-enabled glasses/emitter, Blu-ray 3D drive) and/or software (e.g., Blu-ray 3D discs, 3D middleware, games) are required for the enablement of stereoscopic 3D. Not all features may be supported on all components or systems—check with your component or system manufacturer for specific model capabilities and supported technologies. AMD HD3D™ technology is enabled on AMD Radeon™ HD 7000 Series GPUs and above using Catalyst 12 or later.


AMD POWERTUNE TECHNOLOGY


AMD HD 7000 Series App Acceleration


PCI EXPRESS 3.0

4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.


FAST HDMI technology

HDMI

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7790. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7790 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).

AMD CrossFireX™ multi-GPU technology

CrossFire Ready

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities. AMD CrossFireX™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphics cards ready for practically every budget and the flexibility to combine two GPUs, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

Recommended adapters (active links)

CrossFireX Interconnect - CAC-CB

Multi-Monitor
21.6 Gbps bandwidth

This graphics card is optimized for AMD Eyefinity™ technology and supports the latest generation of display connectivity.

The graphics card features 1 DisplayPort 1.2 outputs with 21.6 Gbps of bandwidth and high bit rate audio. The graphics card features support for by up to six screens simultaneously using AMD Eyefinity™ technology. DisplayPort gives you the flexibility to "Daisy Chain" multiple monitors with a single output and also convert to any desired output. Please refer to Club 3D accessories website for more information.

Video outputsRecommended adapters (active links)

DisplayPort to HDMI cable - CAC-1001
DisplayPort to DVI-D Single-Link cable - CAC-1000
DisplayPort to Active DVI Single-Link cable - CAC-1052



PROTECTIVE CAPS

Dust can collect inside unused video outputs and Electro-Static-Discharge (ESD) by touching the PCB with bare hands while not grounding yourself can be harmful to a graphic card. To protect against dust and ESD Club 3D provides protective caps on the video outputs, CrossFire connector(s) and PCB goldfinger of the graphic card and can prolong the lifespan of your graphic card by up to 65%.

Protective Caps

PDF Download:

Club 3D Radeon HD 7790 royalKing Product Information Sheet [EN]

High Resolution Image:

Club 3D Radeon HD 7790 royalKing high resolution image

Specifications

Model

Product Name: Radeon HD 7790 royalKing
Product Series: Radeon HD 7000
Item Code: CGAX-7792O
EAN Code: 8717249400073

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: Bonaire XT
GPU Clock: 1075 MHz
Stream Processors: 896

Multi-GPU

Multi-GPU: Dual CrossFire Ready

Memory

Memory Size: 1024MB
Memory Interface: 128 BIT
Memory Type: GDDR5
Memory Clock: 6000 MHz

Cooling

Cooling Type: Active Fansink, CoolStream High Performance Cooling Technology

TDP

Idle: 16W
Idle ZCP mode enabled: 3W
Maximum load: 85W

3D API

DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 2 Slots
Profile: Standard profile
Card Size: 198 x 107 x 36 mm

Weight

Card Weight: 482 grams

Output Configuration

DVI: 1x Dual-Link DVI-I
DVI: 1x Dual-Link DVI-D
HDMI: 1x version 1.4a
DisplayPort: 1x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 3

In the package

Club 3D Radeon HD 7790 royalKing graphics card
Club 3D CrossFireX bridge (CAC-CB) interconnect cable
Club 3D knob hanger
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual width X16 lane graphics slot available on the motherboard is required
Minimum of 500 Watt or greater power supply with one 75W 6 pin PCI Express supplementary power connector
Club 3D recommends CSP-S600 600 Watt Switching Power Supply
Minimum 1024MB of system memory (2048MB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D Radeon™ HD 7790 series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit, MCE*

* Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit and Microsoft® Windows® 7 32/64-bit Operating Systems
