CLUB 3D Multi-Stream Transport

Display products have always been an integral part of the PC experience. Whether it's a desktop monitor, a built-in notebook display or the touch screen of a tablet PC is now, display products play a vital role in defining the visual experience of the user.

The Club 3D MST hub is a hub product that receives a DisplayPort ™ 1.2 MST signal from the output product, and this divides the video stream further derive independently on each connected display. By this type of configuration is selected, it is also possible to use non DisplayPort ™ 1.2 monitors. Non DisplayPort ™ outputs are   VGA, DVI or HDMI ®. The Club 3D MST hub is a DP + + product and can convert the DisplayPort ™ active signal on the other types of display interface signals.


Benefits

Increased productivity

The biggest advantage for designers, gamers, or everyone else is an increase in productivity when multiple monitors are used.

A study by Jon Peddie Research shows that productivity increases by an average of 42%, if the user uses multiple displays.

Simultaneous use of multiple programs

Most users have a certain work flow that constitutes the simultaneous use of several programs at any time. If the user uses multiple screens, this is a less strenuous affair and much more productive.

Exchange data

Exchange data between different applications is very common, for example, in an image from a file folder is copied into a Photoshop app. All of these things can be made much easier with the help of multiple screens.


Surface per port


Supplement

Get even more out of your Tablet Surface Pro 2 out with his strong DisplayPort output.

The Microsoft Surface Pro 2 has a powerful Intel Core i5, the fourth generation and with the Club 3D MST hub, it is capable of up to   3 external displays * to control

* 3 if external display is used, the tablet screen turns off

True AudioAMD   TRUE AUDIO & DDM AUDIO

The Club 3D MST Hub supports DisplayPort 1.2 Multi Video and Audio Stremas. Together with AMD Radeon R9 Series 290 and R7 260 Series graphics cards, this provides the first discrete GPU in the world with a programmable audio pipeline. The True Audio technology has been developed for audio artists and engineers in the field of games to make it easier for you to bring your artistic vision processes in the areas of sound production and sound.

Sound is an important but also a critical part of the impressive experience for gamers and sound engineers are eager darafu advance your art, but you has so far received not the same attention as those who have developed the improvements in graphics.

womanphotshop

The ultimate in color and image quality Image Quality

Ideal for Photography, Graphic Design, Media Development and other color-critical applications. A DisplayPort output port can only support 10 bit video *

MST Hub input pixel depth data are 6/8/12 bits and supports output pixel format RGB444
* For a 10-bit video a display is required that   10-bit video support,
a DisplayPort connection between the monitor and graphics card and a graphics card the 10-bit video support. If necessary, you have 10-bit video support in turn the graphics drivers,
software 10 bit drawing through the use of OpenGL or DirectX on Windows,

[Nbsp]

eyefinity

AMD EYEFINITY

Enjoy the ultimate gaming experience beeindruckene

With AMD Radeon based graphics cards, you can up to 6 displays support by You * uses two MST Hubs, during which every monitor or Single Large Surface (SLS) is used

* Required a compatible graphics card that supports at least two DisplayPort outputs and 6 displays.

Dual Mode

Also known as DisplayPort + + can be directly output single-link HDMI, VGA and DVI signals by only a simple passive adapter is used that adjusts the different connectors and the low voltage of DisplayPort. The Club 3D MST Hub makes it easy so you can use any monitor that you want.

Ultrabook

Connect more displays using your Ultrabook

Ultrabooks and notebooks are getting stronger but at the same time also thinner or smaller. DisplayPort offers the flexibility of multiple displays through a single port to operate. The   MST Hub You can work with several displays, and because he is so small, you can simply him home or wherever you go.

[Nbsp]

MST Hub FrontProduct Features

Standard conformity / support: DisplayPort v1.2, DisplayPort v1.1a, VESA DDM

Standard, HDCP V2.0, DisplayId, and EDID V1.4

Supports main link rates of 5.4 bps (HBR2), 2.7 bps (HBR) and 1.62 bps (RBR) of the source

Supports 1/2/4 lanes of the main links for the RX side

Supports DP + + outputs, or two dual-link DVI ports, or the combination of outputs

For DP 1.2 sources supported DP1.2 MST Multi Video / Audio Streams

Supports 1.1 sources supported ViewXpand

Supports DP DP bypass mode

Supports AUX CH and allows SBM and I2C mapping via AUX source and the device

Dedicated I2C slave for the main processor for the connection to the product

Supported Resolution: Up to   2560X1600 @ 60Hz for each monitor in DP1.2 MST and up to FHD/1080p in DP1.1 or DP 1.2 SST

Input Pixel Depth Data 6/8/10/12 bits and supports output pixel format RGB444

Awards

Silver[Nbsp] Oca  recommended

[Nbsp]

PDF Download:

CSV-5300 Product Information Sheet [EN]

High Resolution Image:

CSV-5300 High Resolution Image

Spezifikation

Model

Product Name: Club 3D Multi-Stream Transport (MST) hub
Product Series: SenseVision
Product Code:   CSV-5300
EAN Code:   8717249411918

Interface

Display Port 1.2 Hub 1-3

Voltage

Input: 5V + / - 10%
Output: 3.3V + / - 10%

Output Configuration

DisplayPort 1.2 x 3

In the box

Club 3D Multi-Stream Transport (MST) hub, power supply for the MST hub cable to the AC adapter, User Guide



Systemanforderungen

DisplayPort 1.2 supports up to twice the bandwidth of DisplayPort 1.1a (HBR). High bit-rate 2 (HBR2) delivers up to 5.4Gbps/lane of bandwidth or up to 21.6Gbps in a complete four-lane configuration. This fits well with many applications that have a high demand for ultra Banbreite.

DP 1.2

The number of displays and the timing can be controlled in each of the display depends on the available bandwidth.

HBR

Graphics cards (only those who have DisplayPort or Mini DisplayPort outputs)

HBR (Radeon HD 5000 Series)
HBR2 (Radeon HD 6000 and 7000 Series)

Maximum supported video resolution

Max resolution

Compatible Operating Systems
The DisplayPort 1.2 MST solution was developed with the following Microsoft Windows ® platforms to support:
▪ Windows 8 32-bit version
▪ Windows 8 64-bit version
▪ Windows 7 32-bit version
▪ Windows 7 64-bit version
